Product Description
Product Features
Multiple material options available: standard 304 stainless steel and corrosion-resistant 316L stainless steel, meeting requirements for various corrosive materials; robust structure: integrally formed metal design offering impact resistance, drop protection, and resistance to cracking or damage during high-speed grinding; sealing options include conventional silicone seal, highly corrosion-resistant fluororubber seal, and vacuum-sealed closure; diverse inner wall finishes: brushed surfaces provide wear resistance and durability, while mirror-polished surfaces minimize residue and are easy to clean; suitable for both dry and wet applications, tolerant of most organic solvents and weak acid/alkali environments; comprehensive specifications: standard sizes from 50 mL to 50 L in stock, with external diameter, height, and snap-fit dimensions customizable; excellent thermal conductivity ensures rapid heat dissipation during grinding, preventing material degradation at elevated temperatures; the tank body can be laser-engraved with capacity, logo, and model numbers for easy identification and management.
-
Durable and impact-resistant: Compared to zirconia or alumina ceramic containers, it poses no risk of fracture and offers lower overall long-term costs.
-
Excellent thermal conductivity and heat dissipation: rapid heat generation through grinding, ideal for processing thermosensitive powders.
-
High load-bearing capacity; the large-volume tank features thickened walls, making it suitable for batch grinding of high-density metal powders.
-
High load-bearing capacity; the large-volume tank features thickened walls, making it suitable for batch grinding of high-density metal powders.
Working principle
Place the stainless steel grinding vessel containing grinding media (steel balls or zirconia balls) and the material to be ground into it, seal it tightly, and secure it at the ball mill station.
Planetary grinding machine type: The tank undergoes synchronous revolution and high-speed rotation, with internal grinding balls continuously impacting, crushing, and rubbing the material under the combined effects of centrifugal force, impact force, and friction force, thereby rapidly refining the powder.
Metallurgical industry: crushing and refining of iron powder, alloy powder, and metal ore powder; Chemical coatings: wet grinding of pigments, inks, fillers, and various acid/alkali slurries; New energy industry: vacuum anoxic grinding of graphite and negative electrode materials (using 316L vacuum stainless steel tanks); Building materials refractories: batch grinding of kaolin, quartz sand, and ceramic fillers; Food processing: crushing of grains, spices, and herbal powder (using 304 food-grade stainless steel tanks).
For special operating conditions involving grinding of organic solvents or weak/strong acids/bases: use a 316L stainless steel grinding tank; for oxidizable metal powders or lithium battery materials: employ a vacuum-sealed stainless steel grinding tank; for continuous grinding of large volumes of heavy powders: adopt a thick-walled, high-capacity stainless steel tank; for production workshops with high humidity and moisture content: utilize passivated, rust-resistant stainless steel tanks.
Specification
| orthobaric volume | 50ml/100ml/250ml/500ml/1L/2L/3L/5L/10L/20L/30L/50L, custom non-standard capacities supported |
| Inner Wall Treatment | Matte brushed finish, mirror-polished surface, passivation and rust-proof treatment |
| Associated Consumables |
Stainless steel grinding balls, zirconia grinding balls, sealing gaskets |
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
FAQ
Q: Can you send us product samples?
A: Yes, samples are available. We will charge sample fee and freight.
Q: What is your production lead time?
A: Normally it takes 15-30 working days after receiving the deposit.
Q: Can you send a proforma invoice?
A: Certainly. I will send it to you within today.
Q: Do you sign formal sales contract?
A:Yes, we will make a formal contract for every order.
Q: How do you pack the goods?
A:Packaged in export-standard wooden boxes, suitable for long-distance transportation.
